Key Features
Lumen output & Light source
LEDs provides up to 1958 lm output (@10°, RGBW).
Multiple LED colour variants.
Well homogenised light output with great efficacy up to 65 lm/w.
Multiple LED colour variants.
Well homogenised light output with great efficacy up to 65 lm/w.
Design & Durability
Die cast aluminium body.
IP67 (fixture) / IP65 (tube) and IK10
5 year warranty (registered).
IP67 (fixture) / IP65 (tube) and IK10
5 year warranty (registered).
Flexibility
Indoor and outdoor LED luminaire.
Equipped with three interchangeable lenses.
Offers eleven textured glass options.
Optical components can be replaced on site.
Lighting effects can be adjusted during installation.
Equipped with three interchangeable lenses.
Offers eleven textured glass options.
Optical components can be replaced on site.
Lighting effects can be adjusted during installation.
Connectivity
Interface protocols DMX/RDM or DALI2.
Possibility of control via E-Box range.
(Junction box not included - Optional Accessories)
Possibility of control via E-Box range.
(Junction box not included - Optional Accessories)
Standard Product Versions
RGBW (6500K)
RGBA
PureWhite (3000K)
TW (2200-3000K)
Special Order Options - White Colour Temperature
RED (Upon Request)
GREEN (Upon Request)
BLUE (Upon Request)
AMBER (Upon Request)
2200K (Upon Request)
2700K (Upon Request)
3000K (Upon Request)
4000K (Upon Request)
6500K (Upon Request)
Optic Options
10°, No Optics
Lenses
ARC Lens
Fractal Lens
Line Lens
Textured glass
Hammered
Diamond
Matrix
Cube
DewDrop
Florentine
Cathedral
Ripple
Stream
Aerolite
Flutes
Listral
Control Protocols / Options
Finish / Options
Graphite Black RAL 9011
Grey Aluminium RAL 9007
Pure White RAL 9010
Sandstone RAL 1014
Graphite Black RAL 9011 - Harsh Environment
Grey Aluminium RAL 9007 - Harsh Environment
Pure White RAL 9010 - Harsh Environment
Sandstone RAL 1014 - Harsh Environment
Custom Paint Colour Option
Standards & Certification
IK10
IP65 (Tube)
IP67
5 Years (Registered)
European CE
Vibration IEC60598-1 / 3GANSIC136.31
ETL
UKCA
RoHS
